Pits Atlas: Marius Hills Pit
| Mare pit: Marius Hills | |
|---|---|
| Name | Marius Hills Pit |
| Lat. | 14.0917 |
| Long. | 303.2299 |
| Desc. | Elliptical pit in the middle of a sinuous rille. Floor appears mostly flat, covered in boulders. There are slight overhangs near floor-level on both sides, though there may not be any access to a deeper void space without squeezing through debris. Funnel is ~10 m deep. West Marius Hills pit is ~45km WSW. |
| Types | |
| Terrain | Mare |
| Host Feature | Marius Hills |
| Funnel Min. Diam. | 79 |
| Funnel Max. Diam. | 92 |
| Inner Min. Diam. | 49 |
| Inner Max. Diam. | 55 |
| Azimuth | 65 |
| Depth | 40.0 |
| Depth 1 | N/A |
| Depth 2 | N/A |
| Depth 3 | N/A |
| Best Stereo Left | M1274616922L |
| Best Stereo Right | M1274616922L |
| DTMs | NAC_DTM_MARIUSPIT01 |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | Depth is determined from stereo modelling; image 1/2/3 are merely useful views |
| Entrance Ramp | N |
| Overhang | Y |
| Nearby Pits? | N |
| Nearby Fractures? | N |
| Nearby Depressions? | N |
| In Dome | N |
| Beside Dome | N |
| In Depression | Y |
| Colinear Pits | N |
| Colinear Depressions | N |
| Colinear Fractures | N |
| Marius Hills Pit Shaded Relief | |
|---|---|
 |
| M155607349R | |
|---|---|
 |
|
| Line | 32437 |
| Sample | 723 |
| Inc. Angle | -12.63 |
| Emission Angle | 8.82 |
| Time | 12.08 |
| Resolution | 0.44 |
| M122584310L | |
|---|---|
 |
|
| Inc. Angle | -25.15 |
| Emission Angle | 0.48 |
| Time | 13.46 |
| Resolution | 0.43 |
| M1256963084R | |
|---|---|
 |
|
| Inc. Angle | 28.73 |
| Emission Angle | 0.96 |
| Time | 10.32 |
| Resolution | 0.88 |
| Marius Hills Pit Stereo |
|---|
 |
