Pits Atlas: Central Mare Fecunditatis Pit
| Mare, Large Bowl pit: Mare Fecunditatis | |
|---|---|
| Name | Central Mare Fecunditatis Pit |
| Lat. | -0.9182 |
| Long. | 48.6595 |
| Desc. | Elliptical pit with bowl-shaped floor partly covered in boulders. Walls are ~10 m high, funnel is ~15m deep. SE side is a slope from surface to center of floor with no boulders on it. NE side of floor is less bowl-shaped than the rest, but slewed image of that wall shows no evidence of any overhang. There are no notable features nearby. |
| Types | Large Bowl |
| Terrain | Mare |
| Host Feature | Mare Fecunditatis |
| Funnel Min. Diam. | 162 |
| Funnel Max. Diam. | 198 |
| Inner Min. Diam. | 100 |
| Inner Max. Diam. | 122 |
| Azimuth | 155 |
| Depth | 42.0 |
| Depth 1 | 41.7 |
| Depth 2 | 39.8 |
| Depth 3 | 44.0 |
| Best Stereo Left | M1107968066R |
| Best Stereo Right | M1107968066R |
| DTMs | NAC_DTM_FECNDITATS2 |
| Clipping Width | 300 |
| Other IMGs | |
| Data Warning | |
| Entrance Ramp | Y |
| Overhang | N |
| Nearby Pits? | N |
| Nearby Fractures? | N |
| Nearby Depressions? | N |
| In Dome | N |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | N |
| Colinear Depressions | N |
| Colinear Fractures | N |
| Central Mare Fecunditatis Pit Shaded Relief | |
|---|---|
 |
| M1304478302L | |
|---|---|
 |
|
| Line | 24187 |
| Sample | 3736 |
| Inc. Angle | 57.55 |
| Emission Angle | -1.01 |
| Time | 8.16 |
| Resolution | 0.9 |
| M1129169546R | |
|---|---|
 |
|
| Inc. Angle | -48.55 |
| Emission Angle | -1.92 |
| Time | 15.24 |
| Resolution | 1.05 |
| M1319757415R | |
|---|---|
 |
|
| Inc. Angle | 59.61 |
| Emission Angle | 1.97 |
| Time | 8.03 |
| Resolution | 0.85 |
| Central Mare Fecunditatis Pit Stereo |
|---|
 |
