Pits Atlas: King 33
| Impact Melt pit: King | |
|---|---|
| Name | King 33 |
| Lat. | 6.4873 |
| Long. | 119.6998 |
| Desc. | Teardrop-shaped pit. Floor has a scattering of 0.5-1m boulders, and there’s a ~5m boulder at the S end. There are a few small linear collapse features in the general area, but nothing else that could be called a "pit". |
| Types | |
| Terrain | Impact Melt |
| Host Feature | King |
| Funnel Min. Diam. | 15 |
| Funnel Max. Diam. | 19 |
| Inner Min. Diam. | 11 |
| Inner Max. Diam. | 15 |
| Azimuth | 135 |
| Depth | 7.0 |
| Depth 1 | 6.4 |
| Depth 2 | 5.7 |
| Depth 3 | 9.2 |
| Best Stereo Left | M143839277L |
| Best Stereo Right | M143839277L |
| DTMs | NAC_DTM_KINGCRATER4 |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | |
| Entrance Ramp | N |
| Overhang | ? |
| Nearby Pits? | N |
| Nearby Fractures? | Y |
| Nearby Depressions? | Y |
| In Dome | N |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | N |
| Colinear Depressions | N |
| Colinear Fractures | Y? |
| King 33 Shaded Relief | |
|---|---|
 |
| M113168034R | |
|---|---|
 |
|
| Line | 22490 |
| Sample | 4190 |
| Inc. Angle | 47.55 |
| Emission Angle | 2.15 |
| Time | 8.87 |
| Resolution | 0.62 |
| M106088433L | |
|---|---|
 |
|
| Inc. Angle | -35.09 |
| Emission Angle | 2.06 |
| Time | 14.29 |
| Resolution | 1.29 |
| M185104801R | |
|---|---|
 |
|
| Inc. Angle | -20.77 |
| Emission Angle | 0.16 |
| Time | 13.35 |
| Resolution | 1.27 |
| King 33 Stereo |
|---|
 |
