Pits Atlas: Messier A 4a
| Impact Melt, Fracture pit: Messier A | |
|---|---|
| Name | Messier A 4a |
| Lat. | -2.044 |
| Long. | 46.8825 |
| Desc. | Elongated pit, clearly associated with a fracture system that covers most of a square kilometer, but is not itself attached to a fracture. There's a slight depression running south, where it joins up with some open fractures. There are a couple of other fracture-associate pits in the area of similar depth and lack of open fractures connected to them. Definitely a possibility for sub-surface passageways, if you don't mind falling rocks. |
| Types | Fracture |
| Terrain | Impact Melt |
| Host Feature | Messier A |
| Funnel Min. Diam. | 14 |
| Funnel Max. Diam. | 33 |
| Inner Min. Diam. | 9 |
| Inner Max. Diam. | 22 |
| Azimuth | 175 |
| Depth | 14.0 |
| Depth 1 | 16.0 |
| Depth 2 | 11.8 |
| Depth 3 | >8.0 |
| Best Stereo Left | M190294287L |
| Best Stereo Right | M190294287L |
| DTMs | |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | |
| Entrance Ramp | N |
| Overhang | ? |
| Nearby Pits? | Y |
| Nearby Fractures? | Y |
| Nearby Depressions? | Y? |
| In Dome | N |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | N |
| Colinear Depressions | N |
| Colinear Fractures | Y |
| Messier A 4a Shaded Relief | |
|---|---|
 |
| M126622485R | |
|---|---|
 |
|
| Line | 15398 |
| Sample | 2687 |
| Inc. Angle | 24.74 |
| Emission Angle | 1.25 |
| Time | 10.37 |
| Resolution | 0.44 |
| M185576460R | |
|---|---|
 |
|
| Inc. Angle | -14.27 |
| Emission Angle | -1.74 |
| Time | 12.92 |
| Resolution | 1.04 |
| M159643869L | |
|---|---|
 |
|
| Inc. Angle | 45.12 |
| Emission Angle | -2.94 |
| Time | 9.0 |
| Resolution | 0.43 |
| Messier A 4a Stereo |
|---|
 |
