Pits Atlas: Stevinus 4
| Impact Melt pit: Stevinus | |
|---|---|
| Name | Stevinus 4 |
| Lat. | -32.7245 |
| Long. | 54.1735 |
| Desc. | Semicircular pit, no slopes leading into it, no nearby features. |
| Types | |
| Terrain | Impact Melt |
| Host Feature | Stevinus |
| Funnel Min. Diam. | 15 |
| Funnel Max. Diam. | 15 |
| Inner Min. Diam. | 10 |
| Inner Max. Diam. | 11 |
| Azimuth | 30 |
| Depth | 8.0 |
| Depth 1 | 8.2 |
| Depth 2 | 7.0 |
| Depth 3 | N/A |
| Best Stereo Left | M174929871R |
| Best Stereo Right | M174929871R |
| DTMs | |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | Depths may be from top of funnel, not inner rim. |
| Entrance Ramp | N |
| Overhang | ? |
| Nearby Pits? | N |
| Nearby Fractures? | N |
| Nearby Depressions? | N |
| In Dome | N |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | N |
| Colinear Depressions | N |
| Colinear Fractures | N |
| Stevinus 4 Shaded Relief | |
|---|---|
 |
| M111240262L | |
|---|---|
 |
|
| Line | 32771 |
| Sample | 2921 |
| Inc. Angle | 38.48 |
| Emission Angle | -1.48 |
| Time | 10.4 |
| Resolution | 0.61 |
| M157234690R | |
|---|---|
 |
|
| Inc. Angle | 38.12 |
| Emission Angle | 1.66 |
| Time | 10.8 |
| Resolution | 0.39 |
| Stevinus 4 Stereo |
|---|
 |
