Pits Atlas: Tycho 29b
| Impact Melt pit: Tycho | |
|---|---|
| Name | Tycho 29b |
| Lat. | -42.8473 |
| Long. | 348.5415 |
| Desc. | Rectangular pit part-way up a PRF, center pit of the chain of three. SW wall appears to be a smooth slope to where is disappears into shadow. |
| Types | |
| Terrain | Impact Melt |
| Host Feature | Tycho |
| Funnel Min. Diam. | 14 |
| Funnel Max. Diam. | 18 |
| Inner Min. Diam. | 9 |
| Inner Max. Diam. | 14 |
| Azimuth | 140 |
| Depth | 8.0 |
| Depth 1 | 6.8 |
| Depth 2 | 9.3 |
| Depth 3 | N/A |
| Best Stereo Left | M1206074763L |
| Best Stereo Right | M1206074763L |
| DTMs | |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | Depths are to SW wall/slope, Depth 1 from lower Sun than Depth 2 |
| Entrance Ramp | Y? |
| Overhang | ? |
| Nearby Pits? | Y |
| Nearby Fractures? | Y |
| Nearby Depressions? | Y |
| In Dome | Y |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | Y |
| Colinear Depressions | N |
| Colinear Fractures | N |
| Tycho 29b Shaded Relief | |
|---|---|
 |
| M127008391R | |
|---|---|
 |
|
| Line | 35677 |
| Sample | 3522 |
| Inc. Angle | 51.13 |
| Emission Angle | 2.51 |
| Time | 10.1 |
| Resolution | 0.49 |
| M139979870L | |
|---|---|
 |
|
| Inc. Angle | -41.55 |
| Emission Angle | 2.15 |
| Time | 12.36 |
| Resolution | 0.51 |
| Tycho 29b Stereo |
|---|
 |
