Pits Atlas: Copernicus LB3
| Impact Melt, Large Bowl pit: Copernicus | |
|---|---|
| Name | Copernicus LB3 |
| Lat. | 10.0954 |
| Long. | 339.9231 |
| Desc. | Elliptical pit with very rounded floor (vertical walls are <20m high). Floor is very clear compared to the other Copernicus S_ pits, with most boulders confined to a wedge coming down from the N wall. Drive-in accessibility is limited to a few points along the NE rim, and one gap in the SW rim. |
| Types | Large Bowl |
| Terrain | Impact Melt |
| Host Feature | Copernicus |
| Funnel Min. Diam. | 330 |
| Funnel Max. Diam. | 430 |
| Inner Min. Diam. | 315 |
| Inner Max. Diam. | 385 |
| Azimuth | 60 |
| Depth | 66.0 |
| Depth 1 | 66.0 |
| Depth 2 | 65.0 |
| Depth 3 | >55.0 |
| Best Stereo Left | M1106059896L |
| Best Stereo Right | M1106059896L |
| DTMs | |
| Clipping Width | 800 |
| Other IMGs | |
| Data Warning | |
| Entrance Ramp | Y |
| Overhang | ? |
| Nearby Pits? | N |
| Nearby Fractures? | N |
| Nearby Depressions? | Y |
| In Dome | N |
| Beside Dome | Y |
| In Depression | N? |
| Colinear Pits | N |
| Colinear Depressions | Y |
| Colinear Fractures | N |
| Copernicus LB3 Shaded Relief | |
|---|---|
 |
| M1188488085R | |
|---|---|
 |
|
| Line | 21663 |
| Sample | 3249 |
| Inc. Angle | -68.61 |
| Emission Angle | -1.62 |
| Time | 16.53 |
| Resolution | 0.95 |
| M1142574974L | |
|---|---|
 |
|
| Inc. Angle | -70.97 |
| Emission Angle | 2.34 |
| Time | 16.73 |
| Resolution | 1.19 |
| M102286291L | |
|---|---|
 |
|
| Inc. Angle | -76.82 |
| Emission Angle | 2.86 |
| Time | 17.11 |
| Resolution | 1.25 |
| Copernicus LB3 Stereo |
|---|
 |
