Pits Atlas: Crookes 11b
| Impact Melt pit: Crookes | |
|---|---|
| Name | Crookes 11b |
| Lat. | -10.2372 |
| Long. | 194.7822 |
| Desc. | Rectangular pit, southern of the Crookes 11 pair. SW wall is a slope to floor level, and the floor is mostly clear of boulders. |
| Types | |
| Terrain | Impact Melt |
| Host Feature | Crookes |
| Funnel Min. Diam. | 34 |
| Funnel Max. Diam. | 55 |
| Inner Min. Diam. | 26 |
| Inner Max. Diam. | 28 |
| Azimuth | 30 |
| Depth | 9.0 |
| Depth 1 | 9.8 |
| Depth 2 | 6.5 |
| Depth 3 | 12.0 |
| Best Stereo Left | M176359843R |
| Best Stereo Right | M176359843R |
| DTMs | |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | Depth 2 is from (lower?) W rim. |
| Entrance Ramp | Y |
| Overhang | ? |
| Nearby Pits? | Y |
| Nearby Fractures? | N? |
| Nearby Depressions? | Y |
| In Dome | N |
| Beside Dome | Y |
| In Depression | N |
| Colinear Pits | Y |
| Colinear Depressions | Y? |
| Colinear Fractures | N |
| Crookes 11b Shaded Relief | |
|---|---|
 |
| M1183552745R | |
|---|---|
 |
|
| Line | 31733 |
| Sample | 4544 |
| Inc. Angle | 55.15 |
| Emission Angle | 2.4 |
| Time | 8.36 |
| Resolution | 1.02 |
| M1097573241L | |
|---|---|
 |
|
| Inc. Angle | -56.97 |
| Emission Angle | 0.42 |
| Time | 15.78 |
| Resolution | 1.0 |
| M1119966613L | |
|---|---|
 |
|
| Inc. Angle | 28.45 |
| Emission Angle | -1.08 |
| Time | 10.24 |
| Resolution | 0.93 |
| Crookes 11b Stereo |
|---|
 |
