Pits Atlas: Das 3
| Impact Melt pit: Das | |
|---|---|
| Name | Das 3 |
| Lat. | -26.2963 |
| Long. | 223.0729 |
| Desc. | Roughly rectangular pit. There is some degree of collapse on the south wall, but it does not appear to reach the floor. The floor itself has some non-flatness. There is a shadow edge visible in the slewed image M176171262L that is not visible in the slightly higher-Sun nadir image M1183360718L, indicating a >=2 m deep overhang. There is a small (~3m diameter) depression/pit 70m to the NW, a NNW/SSE-trending linear depression ~300m W, and several other possible depressions running in the same direction in the area. |
| Types | |
| Terrain | Impact Melt |
| Host Feature | Das |
| Funnel Min. Diam. | 21 |
| Funnel Max. Diam. | 23 |
| Inner Min. Diam. | 13 |
| Inner Max. Diam. | 18 |
| Azimuth | 145 |
| Depth | 6.0 |
| Depth 1 | 6.0 |
| Depth 2 | >8.0 |
| Depth 3 | >8.0 |
| Best Stereo Left | M176178010R |
| Best Stereo Right | M176178010R |
| DTMs | |
| Clipping Width | 200 |
| Other IMGs | |
| Data Warning | Floor is only visible in Depth 1 image (and an unused slewed image). Depths 2 and 3 and minimum values. |
| Entrance Ramp | N? |
| Overhang | Y |
| Nearby Pits? | Y? |
| Nearby Fractures? | N |
| Nearby Depressions? | Y? |
| In Dome | N |
| Beside Dome | N |
| In Depression | N |
| Colinear Pits | N |
| Colinear Depressions | Y |
| Colinear Fractures | N |
| Das 3 Shaded Relief | |
|---|---|
 |
| M173817722L | |
|---|---|
 |
|
| Line | 8507 |
| Sample | 4563 |
| Inc. Angle | 35.37 |
| Emission Angle | -0.51 |
| Time | 10.28 |
| Resolution | 0.58 |
| M191494735L | |
|---|---|
 |
|
| Inc. Angle | 59.23 |
| Emission Angle | -1.65 |
| Time | 8.33 |
| Resolution | 0.82 |
| M1183360718L | |
|---|---|
 |
|
| Inc. Angle | 57.53 |
| Emission Angle | -1.7 |
| Time | 8.44 |
| Resolution | 0.85 |
| Das 3 Stereo |
|---|
 |
